Hassas modda 0,01 mm’ye kadar doğruluk
Kompakt görünüm, esnek ve taşınabilir, kullanımı ve taşınması kolay
| Specification | Details |
|---|---|
| Model | Model 93 |
| Light Source | 93 blue laser lines |
| Measurement Rate | 6,700,000 points/s |
| Scan Mode | Wide-Range mode, Standard mode, Precision mode, Deep hole mode |
| Data Precision | 0.02mm (Wide-Range mode), 0.01mm (Standard mode), 0.02mm (Precision mode) |
| Scanning Distance | 370mm (Wide-Range mode, Precision mode), 200mm (Standard mode) |
| Scan Depth of Field | 550mm (Wide-Range mode, Precision mode), 200mm (Standard mode) |
| Resolution | 0.01mm (max) |
| Scanning Area | 600 x 550mm (max) |
| Scanning Range | 0.1 – 10m (expandable) |
| Volume Accuracy (Photogrammetry) | 0.02 + 0.03mm/m |
| Accuracy with Global 3D Photogrammetry System | 0.02 + 0.015mm/m |
| Operating Software | HLScan (free lifetime upgrade) |
| Data Formats | asc, stl, ply, obj, igs, wrl, xyz, txt, etc. (customizable) |
| Compatible Software | 3D Systems (Geomagic Solutions), InnovMetric Software (PolyWorks), Dassault Systemes (CATIA V5, SolidWorks), PTC (Pro/ENGINEER), Siemens (NX, Solid Edge), Autodesk (Inventor, Alias, 3ds Max, Maya, Softimage) |
| Data Transmission | USB 3.0 |
| Computer Configuration (Optional) | Win10 64-bit, Video memory: 4G or above, Processor: I7-13700 or above, Memory: 64GB |
| Laser Safety Level | Class II (eye safety) |
| Laser Certificate Number | LCS200726001DS |
| Weight | 0.92kg |
| Size | 310 x 80 x 139mm |
| Temperature/Humidity | -10—40℃; 10-90% |
| Power Supply | Input: 100-240V, 50/60Hz, 0.9-0.45A; Output: 24V, 1.5A, 36W(max) |
| Certification | CE, IC, FCC, ROHS, ISO9001 |
| Patent | Multiple patents (full list available above) |
| Warranty Period | 24 months |
