Otomatik tarama modu, el tipi tarama modu, iş parçası özelliklerine göre serbestçe seçim modu
Daha hızlı, daha yüksek doğruluk ve daha iyi kararlılık ile tarayın
Sabit ve otomatik nokta bulutu verisi toplama, nokta bulutu verisi elde etmek için el tipi yer işareti noktası birleştirme
Doğruluk 0,01 mm kadar yüksektir ve nesnenin yüzeyindeki ince özellikleri ultra hassas bir şekilde geri yükler.
| Specification Parameters | Details |
|---|---|
| Model | Magic |
| Scanning method | Auto scan mode: Automatic acquisition Handheld scanning mode: Sign point splicing |
| Light source | 49 blue laser lines (wavelength: 450nm) |
| Measurement Rate | 4,200,000 points/s |
| Scan mode | Wide-Range mode: 34 crossed blue laser lines Standard mode: 14 crossed blue laser lines Precision mode: 1 blue laser line Deep hole mode |
| Scanning distance | 650mm (Wide), 330mm (Standard), 650mm (Precision) |
| Scan depth of field | 550mm (Wide), 450mm (Standard), 550mm (Precision) |
| Data precision | 0.02mm |
| Resolution | 0.01mm (max) |
| Scanning area | 800×600mm (max) |
| Scanning range | 0.1–10m (expandable) |
| Volume precision | 0.02+0.03mm/m 0.02+0.015mm/m combined with HL-3DP three-dimensional global photogrammetry system (optional) |
| Operating software | HLScan (free lifetime upgrade) |
| Data formats | asc, stl, ply, obj, igs, wrl, xyz, txt, etc. (customizable) |
| Compatible software | 3D Systems (Geomagic Solutions), InnovMetric Software (PolyWorks), Dassault Systemes (CATIA V5, SolidWorks), PTC (Pro/ENGINEER), Siemens (NX, Solid Edge), Autodesk (Inventor, Alias, 3ds Max, Maya, Softimage) |
| Data transmission | USB 3.0 |
| Computer configuration (optional) | Win10 64-bit; video memory: 4GB+; processor: I7-13700+; RAM: 64GB |
| Laser safety level | ClassⅡ (eye safety) |
| Laser Certification Number | LCS200726001DS |
| Weight | 0.92kg |
| Size | 290x125x70mm |
| Temperature / Humidity | -10—40℃；10–90% |
| Power supply | Input: 100–240V, 50/60Hz, 0.9–0.45A; Output: 24V, 1.5A, 36W (max) |
| Certification | CE, IC, FCC, ROHS, ISO9001 |
| Patent | ZL201220386542.3, ZL201220386546.1, ZL201520174157.6, ZL201721695684.7, ZL201520174106.3, ZL201420058854.0, ZL201721376035.0, ZL201330658475.6, ZL201130007136.2, ZL201130007145.1, ZL201130007141.3, ZL201720362488.1, ZL201720349729.9, ZL201720362493.2, ZL201720369852.7, ZL201720369914.4, ZL201720369921.4, ZL2021102492208.4 |
| Warranty Period | 24 months |
